Smart Glass & Film
We offer installations using either film laminated glass panels, or simply the self-adhesive film itself depending on the exact project at hand. Both provide the same effect demonstrated below
Active
Inactive
Halo Smart Glass
Halo Smart Glass Composition
Multi-purpose laminated Smart Film Glass
Perfect for new constructions
Complete privacy control instantaneously
Add your company logo, design or any shape
Halo Smart Glass is our PDLC film installed between two glass panels, instantly switching from opaque to transparent for dynamic light control. Installed by trained film installers onto existing windows and glass partitions.
Halo Smart Glass Performance
Light Transmission
View angle (ON) >175'
Electrical Parameters
Working Voltage (ON) 48 VAC
Power Consumption < 0.5W/SF
Saturated Voltage (ON) < 25V
Responding Time (OFF-ON) < 200ms
Responding Time (ON-OFF) < 10ms
Switch Speed ON < 200 milliseconds
Switch Speed OFF < 10 milliseconds
Physical Parameters
Glass Type: Low Iron, annealed, heat strengthened, tempered/toughened (all laminated)
Glass Colour: Can be combined with colour interlayers or a wide range of tinted glass to meet any requirement
Max Size 70 inch x 165 inch
Thickness 1/2 inch (5mm + 1.5mm + 5mm)
Thickness 9/16 inch (6mm + 1.5mm + 6mm)
Weight ~5 lbs/sqft
Shape: Any shape or curved including holes, notches, and cut outs
Environmental Parameters
Operating Temperature -4 F - 167 F
Storage Temperature -22 F - 176 F
Lifespan (ON) > 10years
Warranty - 2 - 5 years
